AI that commands
real robots.

APYROBO is the open-source AI orchestration layer for robotics. Connect any LLM to any robot — safely, reliably, without rewriting your ROS 2 stack.

View on GitHub Explore Architecture

Why APYROBO

The AI orchestration layer for physical robots

APYROBO gives AI agents the runtime to act in the physical world. Capability discovery, skill orchestration, swarm coordination, and safety enforcement — one layer, any hardware, any LLM.

🛡️

Safe by construction

Speed clamping, collision zones, watchdog, and battery checks wrap every command. Agents can plan — they can’t bypass safety constraints.

🔌

Hardware-agnostic

Capability adapters abstract any robot behind a semantic API. The same agent code runs on a TurtleBot, a UR arm, or a Boston Dynamics Spot.

🧩

Composable skill graphs

DAG-based task plans with precondition and postcondition verification. Skills chain together — and retry gracefully when the physical world doesn’t cooperate.

🤖

Any LLM, any provider

Model-agnostic agent layer works with OpenAI, Anthropic, Ollama, or any model via LiteLLM. Swap your backend without touching robot code.

🐝

Swarm coordination built in

Multi-robot task splitting, proximity safety, failure reassignment, and deadlock detection — handled natively, not bolted on as an afterthought.

📊

Full observability

Structured JSON logging, Prometheus metrics, OpenTelemetry traces, and execution replay. Know exactly what every agent and robot did, and why.

Architecture

Everything your robot
needs to think and act.

APYROBO is the AI orchestration layer for robotics, built on ROS 2. It adds semantic capability discovery, LLM-driven planning, swarm coordination, and safety enforcement — while keeping the entire ROS 2 ecosystem intact underneath.

🧠

Foundation Models & Research

Vision-language models, policy networks, embodied AI datasets

Open X-EmbodimentHuggingFace RoboticsMulti-modal reasoning

🤖

AI Agents

LLM-powered agents that plan and decide. APYROBO is model-agnostic — use any LLM, cloud or local.

OpenAIAnthropicOllama / LocalCustom agents

⚡

APYROBO — AI Orchestration Layer

The semantic layer above ROS 2: capability discovery, AI agent runtime, skill graph engine, swarm coordination, sensor pipelines, and safety policies

Capability APISkill GraphSwarm CommsSensor PipelinesSafety PoliciesLLM-Agnostic

Open Source

🔧

ROS 2 — Middleware Foundation

The industry standard for robot communication. APYROBO builds on ROS 2 natively — consuming topics, calling action servers, and publishing through standard interfaces.

DDS MessagingNav2MoveItTF Tree

🔬

Simulation Environments

Develop and test in sim, deploy to real hardware — the same APYROBO API works throughout

GazeboIsaac SimWebotsMuJoCo

🦾

Physical Hardware

One framework across any robot, any vendor, any form factor — no vendor lock-in

Boston DynamicsUniversal RobotsUnitreeAgility RoboticsCustom

Execution Model

Physical systems fail.
APYROBO handles it.

Software is deterministic. Robots aren’t. APYROBO’s built-in execution engine treats uncertainty as a first-class concern — surfacing risk before it becomes failure, and recovering gracefully when it does.

01 / PRE-EXECUTION

Capability Contract

Before execution begins, the runtime surfaces a confidence estimate and known risk factors based on current environment state.

task: deliver_package
confidence: 92%
risk: crowded_hallway

02 / DURING

Streaming Verification

A live state machine tracks execution at every step. Deviations are surfaced immediately, not at task completion.

→ position_verified
→ object_detected
→ grasp_confirmed
→ delivered ✓

03 / ON FAILURE

Recovery Policy

Each failure mode maps to a defined recovery path — retry, reroute, escalate, or abort — determined by policy, not the calling agent.

grasp_fail → retry(2)
path_blocked → reroute
sensor_loss → abort

04 / ALWAYS

Safety Envelope

Hard constraints enforced at the infrastructure layer — independent of agent instructions. No agent can override them.

max_speed: 1.2m/s
collision_zone: OFF
human_proximity: 0.5m

The Standard

A protocol,
not just a library.

The APYROBO protocol — capability model, adapter contract, wire protocol, skill manifests — is a language-agnostic specification, frozen at 1.0. Anything the spec covers outlives any one codebase, including ours. Build on the protocol, not the import path.

📜

Spec 1.0 — frozen

Versioned independently of the package; every change goes through a public RFC. Machine-readable JSON Schemas with drift-guard tests keep code and spec from diverging.

✅

Conformance suite

apyrobo conformance runs any adapter or server — in any language — against the spec and emits a verifiable report, backing the “APYROBO Conformant” badge.

🌐

Cross-language, proven

A zero-dependency TypeScript client speaks the wire protocol to apyrobo serve — CI runs it against the Python reference server on every commit.

Hardware Adapters

Any robot.
One API.

APYROBO works with any robot through capability adapters. Bring your own hardware — write a new adapter in minutes and prove it with the conformance suite.

ros2://

ROS2Adapter

The flagship: Nav2 NavigateToPose with cmd_vel fallback. Drives physical robots and live Gazebo sims — verified end-to-end in CI on every commit.

mock://

MockAdapter

Unit testing and development — no hardware or ROS 2 required.

gazebo://

GazeboAdapter

Physics-flavored mock — simulated delays and constraints, no simulator needed. Live simulation runs through ros2://.

yours://

Your adapter

MQTT, REST, or a vendor SDK — apyrobo init --adapter scaffolds a package that passes conformance before you write a line.

See It In Action

Five minutes.
No ROS 2 required.

Install APYROBO, connect to a mock robot, and execute your first natural language task — all without a physical robot or a running ROS 2 stack. Real hardware when you’re ready.

quickstart.py

# pip install apyrobo
from apyrobo import Robot, Agent

# No ROS 2 needed for mock adapter
robot = Robot.discover("mock://turtlebot4")
caps = robot.capabilities()
# → ['navigate_to', 'rotate', 'pick_object', 'place_object']

# No API key needed for rule-based agent
agent = Agent(provider="rule")
result = agent.execute(
  "go to 3, 4 and pick up the object",
  robot
)
print(result.status) # → completed

Recorded demo: a natural-language task planned by the rule agent and executed through Nav2 NavigateToPose, driving a physics-simulated TurtleBot3 in Gazebo

And with physics: the same pipeline against Nav2 in Gazebo — recorded from CI, nothing mocked. The robot discovers, plans, navigates, and reports goal reached. demos/nav2_gazebo ↗

Get Started

From zero to a
commanded robot.

Three steps. The first two need nothing but Python — no ROS 2, no hardware, no API keys.

STEP 01

Install from PyPI

The lean core installs in seconds — two hard dependencies. Add extras when you need them.

pip install apyrobo

STEP 02

Command a mock robot

The quickstart above, verbatim — natural language to executed plan on a laptop.

python demos/drone_survey/demo.py

STEP 03

Add physics

One command boots Gazebo + Nav2 and runs the CI-verified end-to-end (Linux + Docker).

docker compose --profile gazebo-nav run gazebo-nav-demo

PyPI ↗ 5-minute quickstart All demos
